Input/ Turbine Speed Sensor

INPUT/ TURBINE SPEED SENSOR
Inspection
1. Disconnect the negative battery cable.




2. Remove the (left side) front exhaust pipe; use image as reference.




3. Disconnect the Input/ Turbine Speed Sensor connector.







4. Measure the resistance between the terminals of the Input/ Turbine Speed Sensor.
5. If not correct, replace the Input/ Turbine Speed Sensor.
6. Connect the Input/ Turbine Speed Sensor connector.
7. Install the front exhaust pipe.
8. Connect the negative battery cable.
