DTC Memory, Erasing

DTC Memory, Erasing

• If it is not possible to erase DTC memory, check it once again and remedy malfunctions.

Requirements

• DTC memory checked. Refer to => [ DTC Memory, Checking ] DTC Memory, Checking.

• All malfunctions repaired.

After DTC memory has been successfully checked:

Display on (VAS5051):





- Under - 1 - select diagnostic function "05 - Erase DTC memory".

Display on (VAS5051):





1. <> No display (before erasing)

or

<>DTC memory erased

• The following message appears in display zone - 1 -: " DTC memory not yet checked", if the operational sequence was not adhered to exactly. If the DTC memory has been checked beforehand, the DTC memory can only be erased.

2 Note: Should the function be carried out?

• Data will be erased!

- Press OK button in display - 2 -.

- Exit function "05 - Erase DTC memory" by pressing arrow button.

- Check DTC memory again after repair work and erase it if necessary.

• This erases DTCs that have been stored while the malfunction was being fixed, for example, malfunctions that have arisen as a result of connectors being detached.
